Nominal diameter |
Monitor |
Number of pipes |
Heat transfer area |
Channel cross-sectional area Flow rate at 0.5m/sec m/hr |
Pressure | |||||
|---|---|---|---|---|---|---|---|---|---|---|
| Pipe length(m) | φ25×2.5 | |||||||||
| 1500 | 2000 | 3000 | 4000 | 6000 | φ25×2 | |||||
| 159 | I | 14 | 15.162 | 22.17 | 33.27 | - | - | 0.0044/0.0049 | 7.92/8.82 | 0.25 |
| 219 | II | 26/30 | 3/0.0 | 4/4.02 | 6/6.06 | 8/8.1 | - | 0.0082/0.0090 | 14.76/16.20 | 0.6 |
| 219 | II | 3/00 | 3/0.0 | 4/4.02 | 6/6.06 | 8/8.1 | - | 0.0041/0.0045 | 7.38/8.01 | 0.1 |
| 273 | I | 44 | 5/0.0 | 7/5.18 | 10/0.26 | 14/13.72 | 21/20.63 | 0.0038/0.0042 | 28.44/27.36 | 1.6 |
| 273 | II | 40 | 5/4.62 | 6/9.18 | 9/9.33 | 12/12.47 | 19/18.76 | 0.0063/0.0069 | 11.24/12.42 | 0.5 |
| 325 | I | 60/93 | 7/6.93 | 9/8.66 | 14/14.00 | 19/18.71 | 28/28.13 | 0.0188/0.0078 | 33.84/37.44 | 0.6 |
| 325 | II | 56 | 6/6.47 | 9/8.66 | 13/13.05 | 17/17.46 | 36/26.26 | 0.0088/0.0097 | 15.84/17.46 | 0.1 |
| 400 | I | 119 | 14/13.47 | 18/18.41 | 28/27.76 | 37/37.10 | 55/55.8 | 0.0374/0.0412 | 67.32/74.16 | 1.6 |
| 400 | II | 110 | 13/12.70 | 17/17.02 | 26/25.66 | 34/34.20 | 50/51.58 | 0.0130/0.0139 | 31.14/34.20 | 2.5 |
| 500 | I | 185 | - | - | 45/41.5 | 55/57.68 | 85/86.74 | 0.0581/0.0641 | 104.58/115.38 | - |
| 500 | II | 180 | - | - | 40/41.99 | 55/57.68 | 85/86.74 | 0.0283/0.0312 | 50.94/56.16 | - |
| 600 | I | 269 | - | - | 60/62.7 | 85/83.88 | 125/126.13 | 0.0845/0.0932 | 152.10/167.76 | - |
| 600 | II | 266 | - | - | 60/32.05 | 80/82.94 | 125/14.72 | 0.0418/0.0461 | 75.24/83.98 | - |
| 700 | I | 379 | - | - | 90/88.41 | 120/118.17 | 175/177.71 | 0.0091/0.1313 | 214.38/236.34 | - |
| 700 | II | 358 | - | - | 85/83.51 | 110/11.62 | 165/167.85 | 0.0562/0.0620 | 101.16/111.60 | - |
| 800 | I | 511 | - | - | 120/119.20 | 160/159.16 | 240/239.60 | 0.1605/0.1770 | 288.90/318.60 | - |
| 800 | II | 488 | - | - | 115/113.83 | 150/152.16 | 230/228.81 | 0.0767/0.0845 | 138.06/152.10 | - |
| 900 | I | 649 | - | - | 150/151.39 | 200/202.36 | 305/304.3 | 0.2039/0.2248 | 367.02/404.46 | - |
| 900 | II | 630 | - | - | 145/146.96 | 195/196.44 | 295/295.40 | 0.0990/0.1091 | 178.20/196.38 | - |
| 1000 | I | 805 | - | - | 185/187.78 | 250/251.00 | 375/377.45 | 0.2529/0.2788 | 455.22/501.74 | - |
| 1000 | II | 792 | - | - | 185/184.75 | 245/246.95 | 370/371.36 | 0.1244/0.1374 | 223.92/246.96 | - |
