Reaction Kettle

Nominal Volume :
Customizable. Commonly used 50L, 100L, 500L
Design Pressure :
Jacket: Steam 0.3~1.0MPa, Cooling Water 0.2~0.6MPa
Design Temperature :
Reactor internal: -20℃~350℃
Reactor Body Material :
Carbon Steel, 304/316L Stainless Steel

+8613373666051 sales@jswxdhs.com

Product Description

Product Overview

Send Enquiry

Reactors are widely used in fields such as petroleum, chemical, rubber, pesticides, dyes, pharmaceuticals, and food. They are pressure vessels used to complete processes such as vulcanization, nitration, hydrogenation, alkylation, polymerization, and condensation, such as reactors, reaction pots, decomposition pots, polymerization pots, etc; Materials generally include carbon manganese steel, stainless steel, zirconium, nickel based (Hastelloy, Monel, Inconel) alloys, and other composite materials.

Main technical parameters of steam heated stainless steel reaction pot

specifications	Inner cylinder diameter MM	Inner cylinder diameter ΦMM	Electric motor power KW	Gearbox model	Mixing speed r.p.m
30	400	500	0.6~1.1	M2	60~85
50	500	600	0.6~1.1	M3	60~85
100	550	650	1.1~1.5	M4	60~85
150	600	700	2.2	M6	60~85
200	650	750	2.2	M6	60~85
300	800	900	2.2	M6	60~85
500	900	1000	2.2	M6	60~85
800	1100	1200	4	M8	60~85
1000	1200	1300	4	M8	60~85
1500	1300	1400	4	M8	60~85
2000	1400	1500	4	M8	60~85
2500	1400	1500	7.5	BLB7.5-4-13	90
3000	1400	1500	7.5	BLB7.5-4-13	90
3500	1400	1500	7.5	BLB7.5-4-13	90
4000	1500	1600	7.5	BLB7.5-4-13	63
5000	1600	1700	7.5	BLB7.5-4-13	63
6000	1800	1900	15	BLB7.5-4-13	100
8000	2000	2100	15	BLB7.5-4-13	100
32000	3000	3200	37	BLB450-11-45	50~100

Main technical parameters of electric heating stainless steel reaction pot

Reactor specifications (L)	Electric heating power(KW)	Inner pot size (mm)	Clamp size (mm)	Oil jacket capacity(L)	Outer diameter size (mm)	Gearbox model	Motor power	Mixing speed (RPM)	Weight (kg)
30L	3 x 2KW	Φ350	Φ550	50	Φ718x1900	M2	0.55KW	85	250
50L	3 x 2KW	Φ400	Φ600	75	Φ824x2015	M3	0.75KW	85	270
100L	6 x 2KW	Φ500	Φ700	130	Φ1004x2120	M4	1.1KW	85	340
200L	6 x 2KW	Φ600	Φ800	150	Φ1104x2120	M4	1.5KW	85	700
300L	6 x 3KW	Φ700	Φ900	180	Φ1208x2495	M4	2.2KW	85	700
500L	9 x 4KW	Φ900	Φ1100	280	Φ1468x2695	M6	2.2KW	85	930
1000L	12 x 4KW	Φ1200	Φ1400	420	Φ1896x3110	M8	4.0KW	85	1610
2000L	15 x 4KW	Φ1400	Φ1600	740	Φ2005x3500	M8	5.5KW	85	2010
3000L	15 x 4KW	Φ1600	Φ1800	1300	Φ2165x3600	M8	7.5KW	85	2590
4000L	15 x 4KW	Φ1700	Φ1900	1500	Φ2265x3800	M10	11KW	85	3160
5000L	18 x 5KW	Φ1800	Φ2000	1800	Φ2370x4000	M10	15KW	85	4100
6000L		Φ2000	Φ2200	1900	Φ2570x4700	M10	15KW	85	4500
8000L		Φ2200	Φ2400	2100	Φ2900x4700	M12	18.5KW	85	6170
10000L		Φ2400	Φ2600	2400	Φ3150x4900	M12	18.5KW	85	7050
